Release Notes for Catalyst 2820 Series and Catalyst 1900 Series Firmware Version 5.34
Upgrading from Version 5.25 to Version 5.34
78-3817-04
Release Notes for Catalyst 2820 Series and Catalyst 1900 Series Firmware Version 5.34
March 3, 1997
These release notes describe the new features and caveats in the Catalyst 2820 and the Catalyst 1900 Version 5.34 firmware. This firmware runs on the Catalyst 2820 and Catalyst 1900.
The product documentation for the Catalyst 2820 and Catalyst 1900 is as follows:
Catalyst 2820 Series and Catalyst 1900 Series Installation and Configuration Guide
Catalyst 2820 Modules User Guide
Catalyst 2820 Series and Catalyst 1900 Series MIB Reference Manual
New Features
This version adds automatically-refreshed statistics. If you are using VT100 terminal emulation, screens displaying statistics are refreshed every 5 seconds.
Modifications
The following modification is included in Version 5.34:
When port monitoring is enabled with port B as the monitor port, no packets from the ports being monitored are sent to it. Version 5.34 fixes this problem.
Current Caveats
This section lists possibly unexpected behavior by Version 5.34.
Unterminated RS-232 Cables
An RS-232 cable that is connected to a switch-but not connected to a device at the other end-might cause the switch to reset.
Upgrading from Version 5.25 to Version 5.34
If you have customized any Version 5.25 parameters, the upgrade to Version 5.34 resets these parameters to their factory default values. Reset them to your customized settings after the upgrade. (The 5.34 default values of the configurable parameters have not changed from Version 5.25.)
The following parameters return to the listed factory default values when you upgrade to Version 5.34 from 5.25.
Obtaining Service and Support
For service and support for a product purchased from a reseller, contact the reseller. Resellers offer a wide variety of Cisco service and support programs, which are described in the section "Service and Support" in the information packet that shipped with your product.
Note
If you purchased your product from a reseller, you can access Cisco Connection Online (CCO) as a guest. CCO is Cisco Systems' primary, real-time support channel. Your reseller offers programs that include direct access to CCO's services.
For service and support for a product purchased directly from Cisco, use CCO.
Cisco Connection Online
CCO is Cisco Systems' primary, real-time support channel. SMARTnet customers and partners can self-register on CCO to obtain additional information and services.
Note
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Please use CCO to obtain general information about Cisco Systems, Cisco products, or upgrades. If CCO is not accessible, contact 800 553-6387, 408 526-7208, or cs-rep@cisco.com.
