This product bulletin details changes to the Cisco IOS® Software packaging for the Cisco® 3631 Central Office Access Router and the Cisco 3640, 3640A, and 3660 multiservice platforms. In addition, this is an end-of-sales notification for numerous feature sets.
Note: This product bulletin covers the packaging of functions into feature sets. It does not cover individual new features. For information about new features in Cisco IOS Software releases 12.4 Mainline and 12.4T, refer to the Cisco IOS Software pages at Cisco.com.
Note: The last supported release for the Cisco 3620 Multiservice Platform is Cisco IOS Software Release 12.3 Mainline. This bulletin pertains only to the Cisco 3631, 3640, 3640A, and 3660 routers.
OVERVIEW
This product bulletin provides details of feature set availability in Cisco IOS Software releases 12.4 Mainline and 12.4T. The last supported release for the Cisco 3620 Router is Cisco IOS Software Release 12.3 Mainline; hence this platform is not covered by the bulletin.
The last supported release for the Cisco 3640 and 3640A routers is Cisco IOS Software Release 12.4 Mainline. Therefore, these platforms do not appear in the 12.4T section of the bulletin.
CISCO IOS SOFTWARE RELEASE 12.4 MAINLINE
Overview of Available Feature Sets in Cisco IOS Software Release 12.4 Mainline
Table 1 lists Cisco IOS Software Release 12.4 Mainline feature sets that are available for the Cisco 3600 Series multiservice platforms.
Note that the flash memory recommendations given in the table are calculated without added management tools such as Cisco Security Device Manager (SDM).
Table 1. Cisco 3631-12.4M Feature Set Memory Recommendations
Software Product Description
Product ID
Product Description
Image Filename
Recommended Flash 12.4M
Recommended DRAM 12.4M
S363T
Cisco 3631 IOS TELCO FEATURE SET
c3631-telco-mz
32
128
S363TP
Cisco 3631 IOS TELCO PLUS FEATURE SET
c3631-telcoent-mz
64
128
S363TPK9
Cisco 3631 IOS TELCO PLUS FEATURE SET IPSEC 3DES
c3631-telcoentk9-mz
64
128
S364AR1K9
Cisco 3640 IOS ENTERPRISE/SNASW PLUS IPSEC 3DES
c3640-a3jk9s-mz
32
128
S364AR1P
Cisco 3640 IOS ENTERPRISE/SNASW PLUS
c3640-a3js-mz
32
128
S364B
Cisco 3640 IOS IP/IPX/APPLETALK
c3640-bin-mz
16
64
S364BHP
Cisco 3640 IOS IP/IPX/APPLETALK PLUS FW/IDS
c3640-bino3s-mz
32
128
S364BP
Cisco 3640 IOS IP/IPX/APPLETALK PLUS
c3640-bins-mz
32
128
S364C
Cisco 3640 IOS IP
c3640-i-mz
16
64
S364CHK9
Cisco 3640 IOS IP/FW/IDS PLUS IPSEC 3DES
c3640-ik9o3s-mz
32
128
S364CK9
Cisco 3640 IOS IP PLUS IPSEC 3DES
c3640-ik9s-mz
32
128
S364CH
Cisco 3640 IOS IP/FW/IDS
c3640-io3-mz
16
64
S364CP
Cisco 3640 IOS IP PLUS
c3640-is-mz
32
128
S364CU
Cisco 3640 IOS IP/H323
c3640-ix-mz
16
64
S364AHK9
Cisco 3640 IOS ENTERPRISE/FW/IDS PLUS IPSEC 3DES
c3640-jk9o3s-mz
32
128
S364AK9
Cisco 3640 IOS ENTERPRISE PLUS IPSEC 3DES
c3640-jk9s-mz
32
128
S364AP
Cisco 3640 IOS ENTERPRISE PLUS
c3640-js-mz
32
128
S364APU
Cisco 3640 IOS ENTERPRISE PLUS/H323 MCM
c3640-jsx-mz
32
128
S364T
Cisco 3640 IOS TELCO FEATURE SET
c3640-telco-mz
16
64
S366AR1K9
Cisco 3660 IOS ENTERPRISE/SNASW PLUS IPSEC 3DES
c3660-a3jk9s-mz
64
192
S366AR1P
Cisco 3660 IOS ENTERPRISE/SNASW PLUS
c3660-a3js-mz
64
192
S366B
Cisco 3660 IOS IP/IPX/APPLETALK
c3660-bin-mz
16
64
S366BHP
Cisco 3660 IOS IP/IPX/APPLETALK PLUS FW/IDS
c3660-bino3s-mz
32
128
S366BP
Cisco 3660 IOS IP/IPX/APPLETALK PLUS
c3660-bins-mz
32
128
S366C
Cisco 3660 IOS IP
c3660-i-mz
16
64
S366CHK9
Cisco 3660 IOS IP/FW/IDS PLUS IPSEC 3DES
c3660-ik9o3s-mz
64
128
S366CK9
Cisco 3660 IOS IP PLUS IPSEC 3DES
c3660-ik9s-mz
64
128
S366CP
Cisco 3660 IOS IP PLUS
c3660-is-mz
32
128
S366CU
Cisco 3660 IOS IP/H323
c3660-ix-mz
16
64
S366AHK9
Cisco 3660 IOS ENTERPRISE/FW/IDS PLUS IPSEC 3DES
c3660-jk9o3s-mz
64
128
S366AK9
Cisco 3660 IOS ENTERPRISE PLUS IPSEC 3DES
c3660-jk9s-mz
64
128
S366AK9G
Cisco 3660 IOS VOICE IP TO IP VOICE GATEWAY IPSEC 3DES
c3660-jk9s2-mz
64
128
S366AP
Cisco 3660 IOS ENTERPRISE PLUS
c3660-js-mz
64
128
S366APG
Cisco 3660 IOS VOICE IP TO IP VOICE GATEWAY
c3660-js2-mz
64
128
S366APU
Cisco 3660 IOS ENTERPRISE PLUS/H323 MCM
c3660-jsx-mz
64
128
S366T
Cisco 3660 IOS TELCO FEATURE SET
c3660-telco-mz
32
128
S366TP
Cisco 3660 IOS TELCO PLUS FEATURE SET
c3660-telcoent-mz
64
128
S366TPK9
Cisco 3660 IOS TELCO PLUS FEATURE SET IPSEC 3DES
c3660-telcoentk9-mz
64
128
CISCO IOS SOFTWARE RELEASE 12.4T
Overview of Available Feature Sets in Cisco IOS Software Release 12.4T
Table 2 lists the Cisco IOS Software Release 12.3T feature sets that are available for the Cisco 3600 Series routers.
The last supported release for the Cisco 3640 and 3640A routers is Cisco IOS Software Release 12.4 Mainline. Therefore, these platforms do not appear in this section of the bulletin.
Note that the flash memory recommendations in the table are calculated without added management tools such as Cisco SDM.
Table 2. Cisco 3631-12.4T Feature Set Memory Recommendations
Software Product Description
Product ID
Product Description
Image Filename
Recommended Flash 12.4T
Recommended DRAM 12.4T
S363T
Cisco 3631 IOS TELCO FEATURE SET
c3631-telco-mz
32
128
S363TP
Cisco 3631 IOS TELCO PLUS FEATURE SET
c3631-telcoent-mz
64
128
S363TPK9
Cisco 3631 IOS TELCO PLUS FEATURE SET IPSEC 3DES
c3631-telcoentk9-mz
64
128
S366AR1K9
Cisco 3660 IOS ENTERPRISE/SNASW PLUS IPSEC 3DES
c3660-a3jk9s-mz
64
256
S366AR1P
Cisco 3660 IOS ENTERPRISE/SNASW PLUS
c3660-a3js-mz
64
256
S366B
Cisco 3660 IOS IP/IPX/APPLETALK
c3660-bin-mz
32
128
S366BHP
Cisco 3660 IOS IP/IPX/APPLETALK PLUS FW/IDS
c3660-bino3s-mz
64
256
S366BP
Cisco 3660 IOS IP/IPX/APPLETALK PLUS
c3660-bins-mz
64
256
S366C
Cisco 3660 IOS IP
c3660-i-mz
32
128
S366CHK9
Cisco 3660 IOS IP/FW/IDS PLUS IPSEC 3DES
c3660-ik9o3s-mz
64
256
S366CK9
Cisco 3660 IOS IP PLUS IPSEC 3DES
c3660-ik9s-mz
64
256
S366CP
Cisco 3660 IOS IP PLUS
c3660-is-mz
64
256
S366CU
Cisco 3660 IOS IP/H323
c3660-ix-mz
32
128
S366AHK9
Cisco 3660 IOS ENTERPRISE/FW/IDS PLUS IPSEC 3DES
c3660-jk9o3s-mz
64
256
S366AK9
Cisco 3660 IOS ENTERPRISE PLUS IPSEC 3DES
c3660-jk9s-mz
64
256
S366AK9G
Cisco 3660 IOS VOICE IP TO IP VOICE GATEWAY IPSEC 3DES
