This lab focuses on configuring the routers so that you can access them using
either the console port, auxiliary (Aux) port or through a Telnet connection.
It will also have you practice fine tuning different settings on those ports
for increased access control.
This lab has the following objectives:
Available Commands | ||
User EXEC enable |
Privileged EXEC exit |
Global Configuration end |
Line Configuration (console) exec |
Line Configuration (vty) exit |
Line Configuration (aux) exit |
The
above commands are not all available on all of the routers in the simulation.
Use the ? command to determine the commands available on each router.
Click on the Configuration Lab icon to the right to open the interactive simulation environment window in a new browser.
To
enter commands, activate the simulation environment Telnet window by clicking
in it.
To see a list of supported commands at each step of the exercise, you can enter the ? command (press the question mark at the prompt). If you need more help, check the tutorial to review the configuration instructions.
Next, go to Lab: Comm Server configuration.
![]() |
![]() |
![]() |
