Cisco Plug-in for OpenFlow Agent 1.1.5 Release Notes

Supported Hardware

Cisco Plug-in for OpenFlow Agent 1.1.5 is supported on the following devices

• Cisco Nexus 3000 Series Switches
• Cisco Nexus 3100 Series Switches
• Cisco Nexus 3500 Series Switches

– Cisco Nexus 3548-X Switch requires NX-OS 6.0(2)A6(2) or a higher release

Cisco Plug-in for OpenFlow Agent 1.1.4 is supported on all devices that support the Cisco Plug-in for OpenFlow Agent 1.1.0, as well as the following device:

• Cisco Nexus 3100 Series Switches

– Cisco Nexus 3172 Switch

Cisco Plug-in for OpenFlow Agent 1.1.1 is supported on the following devices

• Cisco Nexus 5000 Series Switches

– Cisco Nexus 5596UP Switch

– Cisco Nexus 5548P Switch

– Cisco Nexus 5548UP Switch

• Cisco Nexus 6000 Series Switches

– Cisco Nexus 6001 Switch

– Cisco Nexus 6004 Switch

Cisco Plug-in for OpenFlow Agent 1.1.0 is supported on the following devices

• Cisco Nexus 3000 Series Switches

– Cisco Nexus 3016 Switch

– Cisco Nexus 3064 Switch

– Cisco Nexus 3064-T Switch

– Cisco Nexus 3048 Switch

• Cisco Nexus 3100 Series Switches

– Cisco Nexus 3132Q Switch

For additional information about Cisco Nexus Switches see the documentation at:

http://www.cisco.com/en/US/products/ps11541/tsd_products_support_series_home.html

Resolved Caveats—Cisco Plug-in for OpenFlow Agent 1.1.5

There are no new caveats resolved in Cisco Plug-in for OpenFlow Agent 1.1.5.

Open Caveats—Cisco Plug-in for OpenFlow Agent 1.1.5

This section describes possibly unexpected behavior by Cisco Plug-in for OpenFlow Agent 1.1.5. All the caveats listed in this section are open in Cisco Plug-in for OpenFlow Agent 1.1.5. This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCuq39973

Symptoms: OpenFlow container flaps.

Conditions: This symptom is seen when the show openflow switch 1 flows or show openflow switch 1 brief commands do not respond for a long time when there are 32K MAC and 700 ACL flows created. This does not happen always, but frequently such non-responsive behavior could result in a container restart.

Workaround: Do not use the show openflow switch 1 flows or show openflow switch 1 brief commands when there are a large number of flows created. Instead, use controller commands or native switch commands such as show mac address-table or show access-list access-list-name.

• CSCup05121

Symptoms: Error returned for FLOW_MOD with exact match for VLAN ID 65535.

Conditions: This symptom is seen when the Floodlight controller sends a FLOW_MOD that includes an exact match for VLAN ID 65535.

Workaround: There is no known workaround.

Resolved Caveats—Cisco Plug-in for OpenFlow Agent 1.1.4

The caveats in this section are resolved in Cisco Plug-in for OpenFlow Agent 1.1.4 but may be open in previous Cisco Plug-in for OpenFlow Agent releases.

• CSCuo27972

Symptoms: If an OpenFlow controller sends a packet-out message with multiple output actions, only the first output action will be honored, and the rest will be ignored.

Conditions: There are no conditions.

Workaround: If possible, change the controller to send multiple, separate packet-out messages.

• CSCum77755

Symptoms: In scale testbeds with more than 1000 flows, the virtual service restarts when the OpenFlow switch is shut down.

Conditions: This symptom is seen when the 'logging flow-mod' configuration is enabled, and the OpenFlow switch is shut down when there are more than 1000 flows installed on the switch.

Workaround: Disable the 'logging flow-mod' configuration on OpenFlow switches that have a large number of flows installed.

• CSCum05753

Symptoms: The OpenFlow Agent does not send a TABLE_FULL Error when the OFA flow table is full.

Conditions: This symptom is seen when the maximum supported flows for any table are already installed, and the controller attempts to add addition flows. The flow additions fail, and error messages are sent to the controller. However, the error is not the TABLE_FULL error.

Workaround: There is no workaround.

• CSCun16999

Symptoms: The number of maximum flows supported in Pipeline 202 for the MAC forwarding table is displayed wrongly as 50K.

Conditions: This symptom is seen in the output of the show openflow swithch 1 stats command.

Workaround: There is no workaround.

• CSCul65769

Symptoms: Sometimes, some of the flows fail to get installed.

Conditions: This symptom is usually seen in scale testbeds.

Workaround: There is no workaround.

• CSCum51332

Symptoms: After configuring the default-miss, the continue-normal command is configured under OpenFlow configuration. If the switch is flapped, that is, if a shutdown or no shutdown command is issued, the default rule action is drop instead of normal.

Conditions: This symptom is seen because of the OpenFlow configuration, where the table supports any default-miss action other than drop.

Workaround: Unconfigure the default-miss CLI and reconfigure it.

Open Caveats—Cisco Plug-in for OpenFlow Agent 1.1.4

This section describes possibly unexpected behavior by Cisco Plug-in for OpenFlow Agent 1.1.4. All the caveats listed in this section are open in Cisco Plug-in for OpenFlow Agent 1.1.4. This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCup05121

Symptoms: Errors are displayed on the Floodlight console when the Floodlight controller sends a FLOW_MOD that includes an exact match for VLAN ID 65535.

Conditions: This symptom is seen in the Cisco Plug-In for OpenFlow on Cisco Nexus 3000/3100/3500 platforms when the Floodlight OpenFlow controller runs the Learning Switch module.

Workaround: There is no workaround.

Resolved Caveats—Cisco Plug-in for OpenFlow Agent 1.1.3

The caveats in this section are resolved in Cisco Plug-in for OpenFlow Agent 1.1.3 but may be open in previous Cisco Plug-in for OpenFlow Agent releases.

• CSCuj67125

Symptoms: Pipeline 202 accepts mandatory destination and source MAC addresses.

Conditions: This symptom is seen when flows are added to pipeline 202 with a wild card MAC destination address or VLAN ID.

Workaround: There is no workaround.

• CSCum59162

Symptoms: OpenFlow memory allocation increases if the rate of packets that are being punted to the controller increases to more than 2000 packets per second (pps). If this rate persists over a long time, then the OpenFlow agent could run out of memory and restart.

Conditions: This symptom is seen with a persistent rate of more than 2000 pps being sent to the controller.

Workaround: Reduce the rate of packets being sent to the controller to the supported rate of around 1000 pps. The control plane policing policy can be configured to 1000 pps to limit the rate of incoming packets.

• CSCum16341

Symptoms: The default flow for the table is counted as part of the number of active flows. Hence, the table cannot install the maximum number of supported flows.

Conditions: This symptom is seen when a default flow is installed for the table. This flow gets incorrectly counted as an active flow. Tables should be able to install the default flow and the maximum supported flows.

Workaround: There is no workaround.

• CSCun60908

Symptoms: OpenFlow channel connections to a controller fail when using TLS.

Conditions: This symptom is seen when the Certificate Authority (CA) certificates are a series of chained certificates.

Workaround: Use raw TCP for the OpenFlow channel connection to the controller.

• CSCul67703

Symptoms: With pipeline 202, when the default-miss is configured to drop, two default flows are added—one each for the ACL and the MAC table. The ACL table installs a default rule of 'permit' to allow packet matching in the MAC table. The MAC table installs a default rule of 'drop' to drop all un-matched packets.

Conditions: This symptom is seen when the switch is configured to use pipeline 202 and the default-miss is configured as 'drop'.

Workaround: The show ip access-lists | beg onep command can be used to display the rule that is actually installed in the ACL table. The default rule will be similar to the following:

permit ip any any priority -1

• CSCuj08625

Symptoms: Flow Packet counters are different in the output of the show ip access-list and the show openflow switch 1 flow commands.

Conditions: This symptom is seen because the hardware counters are 64-bit long and the OpenFlow counters are 32-bit long and because the counters will start to get different after there have been 2^32 packets that match the flow.

Workaround: Get the flow match counters from the output of the show ip access-list command instead of the show openflow switch 1 flow command.

• CSCum20786

Symptoms: Flow addition in table 0 (ACL table) is faster in Pipeline 201 compared to Pipeline 202.

Conditions: This symptom is seen when flows are added to the ACL table in Pipeline 202.

Workaround: There is no workaround.

Open Caveats—Cisco Plug-in for OpenFlow Agent 1.1.3

This section describes possibly unexpected behavior by Cisco Plug-in for OpenFlow Agent 1.1.3. All the caveats listed in this section are open in Cisco Plug-in for OpenFlow Agent 1.1.3. This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCum51332

Symptoms: After configuring the default-miss, the continue-normal command is configured under OpenFlow configuration. If the switch is flapped, that is, if a shutdown or no shutdown command is issued, the default rule action is drop instead of normal.

Conditions: This symptom is seen because of the OpenFlow configuration, where the table supports any default-miss action other than drop.

Workaround: Unconfigure the default-miss CLI and reconfigure it.

• CSCuj44931

Symptoms: The MAC Forwarding Table flows are all configured as static entries and all the flows have the same priority. Also, the MAC table supports exact matching on the destination MAC address and the vlan ID, and the only actions supported are drop and output to port.

However, the OpenFlow Agent will accept flow add/modify messages for the MAC flows with configurations for the flow priority and the idle/hard timeouts, and matching on other fields. These invalid matches or actions are ignored and the flow is still installed in the MAC table with only the correct supported attributes.

Conditions: This is seen when the OpenFlow switch is configured with pipeline 202, and when flow add messages include unsupported matches and actions such as setting the flow priority, setting the idle or hard timeouts, matching on IP source or destination address, TCP or UDP protocol, TOS, and Layer 4 source or destination ports.

Workaround: Install flows with only the supported matches and actions for the MAC Forwarding Table in Pipeline 202.

Resolved Caveats—Cisco Plug-in for OpenFlow Agent 1.1.2

The caveats in this section are resolved in Cisco Plug-in for OpenFlow Agent 1.1.2 but may be open in previous Cisco Plug-in for OpenFlow Agent releases.

• CSCul65769

Symptoms: Sometimes some of the flows fail to get installed. This is usually seen in scale testbeds.

Conditions: This symptom is seen in scale testbeds.

Workaround: After the flows are added, you can use the output of show openflow switch 1 flows summary and show openflow switch 1 controller stats to ensure that all the flows are correctly installed. Or check for error messages from the agent during flow setup on the controller. If any errors are found, readd only the failed flows and ensure it was successfully added.

Open Caveats—Cisco Plug-in for OpenFlow Agent 1.1.2

This section describes possibly unexpected behavior by Cisco Plug-in for OpenFlow Agent 1.1.2. All the caveats listed in this section are open in Cisco Plug-in for OpenFlow Agent 1.1.2. This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCuj02751

Symptoms: For pipeline 202, the lookups & match counters for Table 1, MAC Forwarding Table, do not increment even though the traffic matches the MAC table flow rules. Instead the counters increment for Table 0 as the packets match the default rule in the ACL table.

Conditions: This symptom occurs when pipeline 202 is configured for the openflow switch and traffic matches flow in the MAC Forwarding Table.

Workaround: There is no workaround.

• CSCuj07822

Symptoms: When a significant number of flows are added while debug commands are turned on, the CLI hangs momentarily before eventually recovering automatically.

Conditions: This symptom occurs when a significant number of flows are simultaneously programmed and when debugs are turned on.

Workaround: Turn off the debugs or limit the number of debugs being turned on. Or wait until the flows are setup before running the show commands.

• CSCuj44931

Symptoms: The Mac Forwarding Table flows are all configured as static entries and all the flows have the same priority. Also, the MAC table supports the exact matching on the destination MAC address and the VLAN ID, and the only actions supported are drop and output to port.

However, the Openflow Agent will accept flow add/modify messages for the MAC flows with configurations for the flow priority and the idle/hard timeouts, and matching on other fields. These invalid matches/actions are ignored and the flow is still installed in the MAC table with only the correct supported attributes.

Conditions: This symptom occurs when the openflow switch is configured with pipeline 202 and flow add messages include unsupported matches and actions like setting the flow priority, setting the idle/hard timeouts, matching on IP src/dest address, TCP/UDP protocol, TOS, L4 src/dest ports etc.

Workaround: Install flows with only the supported matches and actions for the MAC Forwarding Table in Pipeline 202.

• CSCul67703

Symptoms: With pipeline 202, when the default-miss is configured to drop, two default flows are added, one each for the ACL and the MAC table. The ACL table installs a default rule of “permit” to allow packet matching in the MAC table. The MAC table installs a default rule of “drop” to drop all unmatched packets.

However, “show openflow switch 1 flows” displays both the rules to have the action “drop” instead of having the action “goto” or “normal” for the table 0.

Conditions: This symptom occurs when the switch is configured to use pipeline 202 and the default-miss is configured as “drop”.

Workaround: The show ip access-lists | beg onep command can be used to display the rule that is actually installed in the ACL table. The default rule will be similar to the following:

• CSCul70028

Symptoms: When the Openflow agent-installed default flow is modified by adding another default rule from the controller, the following issues are observed

1. The show openflow switch 1 flows controller command does not show this controller installed default flow

2. When the controller tries to fetch flow stats for this default flow, the Openflow agent does not provide the stats for this default flow.

Conditions: This symptom occurs when the Openflow agent-installed default flow is over-ridden by another default rule installed by the controller.

Workaround: The controller-installed default flow can be seen with the show openflow switch 1 flows default command. However, the stats for this default flow will not be sent to the controller.

• CSCul87549

Symptoms: The OpenFlow plugin incorrectly sends an OFPHFC_INCOMPATIBLE error in response to an OFPT_FLOW_MOD message.

Conditions: This symptom occurs when an attempt is made to program a flow using matches not supported by the configured pipeline.

Workaround: Ensure that the flows are programmed with matches/actions that are supported for the pipeline.

• CSCum22686

Symptoms: There is a mismatch between controller flows and the ACL entries.

Conditions: This symptom occurs while performing the open flow switch unconfiguration and configuration. Either copy/paste or copying to the running configuration may create the issue.

Workaround: Perform shutdown/no shutdown under the open flow switch configuration.

• CSCum59162

Symptoms: Openflow memory allocation increases if the rate of packets being punted to the controller increases at more than 2000 packets per second (pps). If this rate persists over a long time, then the openflow agent could run out of memory and restart.

Conditions: This symptom is seen with a persistent rate of more than 2000 pps being sent to the controller.

Workaround: Reduce the rate of packets being sent to the controller to the supported rate of around 1000 pps. The control plane policing policy can be configured to 1000 pps to limit the rate of incoming packets.

• CSCuj08625

Symptoms: Flow packet counters are different in the outputs of the show ip access-list and the show openflow switch 1 flow commands.

Conditions: This symptom occurs because the hardware counters are 64 bit long and the openflow counters are 32 bit long, and the counters will start to get different after there have been 2^32 packets that match the flow.

Workaround: Get the flow match counters from the output of the show ip access-list command instead of the show openflow switch 1 flow command.

• CSCum77755

Symptoms: In scale testbeds with more than 1000 flows, the virtual service restarts when the openflow switch is shutdown.

Conditions: This symptom is seen when the logging flow-mod command is enabled and the openflow switch is shutdown when there are more than 1000 flows installed on the switch.

Workaround: Disable logging flow-mod on openflow switches that have a large number of flows installed.

• CSCum05753

Symptoms: The Openflow Agent does not send a “TABLE_FULL” error when the OFA flow table is full.

Conditions: This symptom is seen when the maximum supported flows for any table are already installed and the controller attempts to add additional flows. The flow adds fail and error messages are sent to the controller. However, the error is not the “TABLE_FULL” error.

Workaround: There is no workaround. There is no functional impact to this bug.

Open Caveats—Cisco Nexus 3000 Series Switches (1.1.2)

This section describes possibly unexpected behavior in the underlying Cisco NX-OS system software which may affect the behavior of Cisco Plug-in for OpenFlow Agent 1.1.2. All the caveats listed in this section are open in Cisco NX-OS 6.0(2)U2(2). This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCui25370

Symptom: CLI commands added by a container-based onePK application may not be removed when a container fails to install following a reboot.

Conditions: A container-based onePK application adds CLI commands to the router using the onePK CLI extensions feature. Upon reboot of the router the container fails to install properly. The CLI commands added prior to rebooting still remain even though the container is no longer installed.

Workaround: Install and uninstall the container for a second time to clean up the remaining CLI commands.

• CSCuj70716

Symptom: The following system message seen on uninstalling ova. There is no functionality impact.

Conditions: The symptom is seen after uninstalling ova.

Workaround: No workaround is needed as there is no functionality impact.

• CSCul69881

Symptom: Flows are created for non-existing vlans.

Conditions: Install flows with non existing vlans on the agent via controller and the agent accepts the flows.

Correct Behaviour: Agent should reject the flow

Workaround: There is no workaround.

• CSCum11307

Symptom: A core is observed while adding and deleting flows on Cisco Nexus 5000 series switches and Cisco Nexus 3000 series switches.

Conditions: The core that is observed seems to be an intermittent problem that does not occur or happen every time we add / delete 1500 flows. The element chunk memory that gets freed on xos_list_remove is not yet overwritten or used when the next call to xos_list_get_next() is made most of the times (xos is just freeing not setting the parameter to null).

Workaround: There is no workaround. This issue is not seen consistently.

• CSCum16186

Symptom: A deadlock in the Netstack or DPSS components blocks the openflow agent process until the process is killed by the watchdog timer.

Conditions: This symptom is seen when the openflow agent is repeatedly unconfigured, configured, shut, and no-shut in a continuous cycle. It usually takes about 15-20 cycles for the deadlock to occur and for the process to crash.

Workaround: Enter the switch unconfiguration or configuration command manually or slower with a few seconds between each command.

• CSCum23124

Symptom: Sometimes when openflow is enabled and unconfigured using the no openflow global configuration command, an error is seen when a proper cleanup of configuration is done. This issue has no functionality impact.

Conditions: This symptom is seen in the “no openflow” configuration.

Workaround: There is no workaround.

• CSCum63392

Symptom: The openflow interface link or operational state remains “UP” even if the cable is removed and the physical interface state goes down.

Conditions: This symptom is seen if the interface is initially “UP” and once it is added to the openflow switch, the interface state goes down.

Workaround: Admin shut and no shut of the interface will correctly update the interface state.

Resolved Caveats—Cisco Plug-in for OpenFlow Agent 1.1.1

The caveats in this section are resolved in Cisco Plug-in for OpenFlow Agent 1.1.1 but may be open in previous Cisco Plug-in for OpenFlow Agent releases.

• CSCum08772

Symptoms: The Openflow agent gets killed due to lack of memory.

Conditions: This symptom occurs when there are flows installed that punt the packets to the controller. The packet buffer is not freed and gets leaked. This is seen with scale tests when packets get punted to the controller in large numbers at a very high rate.

Workaround: Do not add flows that punt the packets to the controller.

Open Caveats—Cisco Plug-in for OpenFlow Agent 1.1.1

This section describes possibly unexpected behavior by Cisco Plug-in for OpenFlow Agent 1.1.1. All the caveats listed in this section are open in Cisco Plug-in for OpenFlow Agent 1.1.1. This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCuj02751

Symptoms: For pipeline 202, the lookups & match counters for Table 1, MAC Forwarding Table, do not increment even though the traffic matches the MAC table flow rules. Instead the counters increment for Table 0 as the packets match the default rule in the ACL table.

Conditions: This symptom occurs when pipeline 202 is configured for the openflow switch and traffic matches flow in the MAC Forwarding Table.

Workaround: There is no workaround.

• CSCuj07822

Symptoms: When a significant number of flows are added while debug commands are turned on, the CLI hangs momentarily before eventually recovering automatically.

Conditions: This symptom occurs when a significant number of flows are simultaneously programmed and when debugs are turned on.

Workaround: Turn off the debugs or limit the number of debugs being turned on. Or wait until the flows are setup before running the show commands.

• CSCuj44931

Symptoms: The Mac Forwarding Table flows are all configured as static entries and all the flows have the same priority. Also, the MAC table supports the exact matching on the destination MAC address and the VLAN ID, and the only actions supported are drop and output to port.

However, the Openflow Agent will accept flow add/modify messages for the MAC flows with configurations for the flow priority and the idle/hard timeouts, and matching on other fields. These invalid matches/actions are ignored and the flow is still installed in the MAC table with only the correct supported attributes.

Conditions: This symptom occurs when the openflow switch is configured with pipeline 202 and flow add messages include unsupported matches and actions like setting the flow priority, setting the idle/hard timeouts, matching on IP src/dest address, TCP/UDP protocol, TOS, L4 src/dest ports etc.

Workaround: Install flows with only the supported matches and actions for the MAC Forwarding Table in Pipeline 202.

• CSCul67703

Symptoms: With pipeline 202, when the default-miss is configured to drop, two default flows are added, one each for the ACL and the MAC table. The ACL table installs a default rule of “permit” to allow packet matching in the MAC table. The MAC table installs a default rule of “drop” to drop all unmatched packets.

However, “show openflow switch 1 flows” displays both the rules to have the action “drop” instead of having the action “goto” or “normal” for the table 0.

Conditions: This symptom occurs when the switch is configured to use pipeline 202 and the default-miss is configured as “drop”.

Workaround: The show ip access-lists | beg onep command can be used to display the rule that is actually installed in the ACL table. The default rule will be similar to the following:

• CSCul70028

Symptoms: When the Openflow agent-installed default flow is modified by adding another default rule from the controller, the following issues are observed

1. The show openflow switch 1 flows controller command does not show this controller installed default flow

2. When the controller tries to fetch flow stats for this default flow, the Openflow agent does not provide the stats for this default flow.

Conditions: This symptom occurs when the Openflow agent-installed default flow is over-ridden by another default rule installed by the controller.

Workaround: The controller-installed default flow can be seen with the show openflow switch 1 flows default command. However, the stats for this default flow will not be sent to the controller.

• CSCul87549

Symptoms: The OpenFlow plugin incorrectly sends an OFPHFC_INCOMPATIBLE error in response to an OFPT_FLOW_MOD message.

Conditions: This symptom occurs when an attempt is made to program a flow using matches not supported by the configured pipeline.

Workaround: Ensure that the flows are programmed with matches/actions that are supported for the pipeline.

• CSCum22686

Symptoms: There is a mismatch between controller flows and the ACL entries.

Conditions: This symptom occurs while performing the open flow switch unconfiguration and configuration. Either copy/paste or copying to the running configuration may create the issue.

Workaround: Perform shutdown/no shutdown under the open flow switch configuration.

• CSCum59162

Symptoms: Openflow memory allocation increases if the rate of packets being punted to the controller increases at more than 2000 packets per second (pps). If this rate persists over a long time, then the openflow agent could run out of memory and restart.

Conditions: This symptom is seen with a persistent rate of more than 2000 pps being sent to the controller.

Workaround: Reduce the rate of packets being sent to the controller to the supported rate of around 1000 pps. The control plane policing policy can be configured to 1000 pps to limit the rate of incoming packets.

• CSCuj08625

Symptoms: Flow packet counters are different in the outputs of the show ip access-list and the show openflow switch 1 flow commands.

Conditions: This symptom occurs because the hardware counters are 64 bit long and the openflow counters are 32 bit long, and the counters will start to get different after there have been 2^32 packets that match the flow.

Workaround: Get the flow match counters from the output of the show ip access-list command instead of the show openflow switch 1 flow command.

• CSCum77755

Symptoms: In scale testbeds with more than 1000 flows, the virtual service restarts when the openflow switch is shutdown.

Conditions: This symptom is seen when the logging flow-mod command is enabled and the openflow switch is shutdown when there are more than 1000 flows installed on the switch.

Workaround: Disable logging flow-mod on openflow switches that have a large number of flows installed.

• CSCul65769

Symptoms: Sometimes some of the flows fail to get installed. This is usually seen in scale testbeds.

Conditions: This symptom is seen in scale testbeds.

Workaround: After the flows are added, you can use the output of show openflow switch 1 flows summary and show openflow switch 1 controller stats to ensure that all the flows are correctly installed. Or check for error messages from the agent during flow setup on the controller. If any errors are found, readd only the failed flows and ensure it was successfully added.

• CSCum05753

Symptoms: The Openflow Agent does not send a “TABLE_FULL” error when the OFA flow table is full.

Conditions: This symptom is seen when the maximum supported flows for any table are already installed and the controller attempts to add additional flows. The flow adds fail and error messages are sent to the controller. However, the error is not the “TABLE_FULL” error.

Workaround: There is no workaround. There is no functional impact to this bug.

Open Caveats—Cisco Nexus 5000 and Nexus 6000 Series Switches

NX-OS 7.0(0)N1(1)

This section describes possibly unexpected behavior in the underlying Cisco NX-OS system software which may affect the behavior of Cisco Plug-in for OpenFlow Agent 1.1.1. All the caveats listed in this section are open in Cisco NX-OS 7.0(0)N1(1). This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCui25370

Symptom: CLI commands added by a container-based onePK application may not be removed when a container fails to install following a reboot.

Conditions: A container-based onePK application adds CLI commands to the router using the onePK CLI extensions feature. Upon reboot of the router the container fails to install properly. The CLI commands added prior to rebooting still remain even though the container is no longer installed.

Workaround: Install and uninstall the container for a second time to clean up the remaining CLI commands.

• CSCuj45245

Symptom: The following error message is seen:

Conditions: This symptom is an intermittent issue seen after some triggers, for example, clear controller command, switch unconf/conf, switch shut/noshut, cotroller unconf/conf etc.

Workaround: Virtual-service deactivate & reactivate fixes this issue.

• CSCuj66918

Symptom: All packets do not reach the controller from the Cisco Nexus 3064 switch at 500pps to 1000pps. There is no issue is on the Cisco Nexus 3048 switch.

Conditions: The symptom is seen under the following conditions:

– About 1700 packets reached the controller when 2000 lldp packets were sent to the controller at 500pps.

– About 1050 packets reached the controller when 2000 lldp packets were sent to the controller at 1000pps.

Workaround: There is no workaround.

• CSCuj70716

Symptom: The following system message seen on uninstalling ova. There is no functionality impact.

Conditions: The symptom is seen after uninstalling ova.

Workaround: No workaround is needed as there is no functionality impact.

• CSCul48306

Symptom: A deadlock in the Netstack or DPSS components blocks the openflow agent process until the process is killed by the watchdog timer.

Conditions: This symptom is seen when the openflow agent is repeatedly unconfigured, configured, shut, and no-shut in a continuous cycle. It usually takes about 15-20 cycles for the deadlock to occur and for the process to crash.

Workaround: Enter the switch unconfiguration or configuration command manually or slower with a few seconds between each command.

• CSCul99528

Symptom: The openflow-agent logical-switch configuration default-miss cascade normal does not take effect in pipeline 201.

Conditions: This symptom is seen in the openflow pipeline 201 mode when the incoming packets do not match any of the flows installed and cannot be subjected to the regular forwarding logic in pipeline 201.

Workaround: Openflow logical switch configuration can be changed to pipeline 202 in which the default-miss cascade normal works as expected.

Further Problem Description: The following are the steps to reproduce this symptom:

1. Configure pipeline 201.

2. Configure the openflow logical-switch configuration default-miss cascade normal.

3. Configure two ports in openflow with the same vlan configuration.

4. Check if no flow is installed and if the traffic is following as per the normal forwarding path.

5. Check whether all openflow ports in same vlan are receiving the packets.

Traffic does not get forwarded to the destination eventhough the ports are in the same vlan.

• CSCum23745

Symptom: On Flapping OF switch with 1200 acl flows installed and sending traffic at line rate(10Gb) large ONEP mem-leak is observed.

Conditions: This symptom is seen After installing 1200 and could see huge memory leak at ONEP CLI extensions code and also in other places too.

Workaround: There is no workaround.

• CSCum79887

Symptom: In the monitor-manager based openflow topology when there is a flow with the port-channel as the output port then the traffic drop might happen when the port-channel link is flapped or a link failure happens. In this case the monitor-monitor recalculates the topology and tries to forward packets using the next available path which fails due to the software issue.

Conditions: This symptom is seen in the monitor-manager based openflow topology when there is a flow with the port-channel as the output port.

Workaround: Perform a shut and no-shut of the openflow logical switch.O

Open Caveats—Cisco Plug-in for OpenFlow Agent 1.1.0

This section describes possibly unexpected behavior by Cisco Plug-in for OpenFlow Agent 1.1.0. All the caveats listed in this section are open in Cisco Plug-in for OpenFlow Agent 1.1.0. This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCuj02751

Symptoms: For pipeline 202, the lookups & match counters for Table 1, MAC Forwarding Table, do not increment even though the traffic matches the MAC table flow rules. Instead the counters increment for Table 0 as the packets match the default rule in the ACL table.

Conditions: This symptom occurs when pipeline 202 is configured for the openflow switch and traffic matches flow in the MAC Forwarding Table.

Workaround: There is no workaround.

• CSCuj07822

Symptoms: When a significant number of flows are added while debug commands are turned on, the CLI hangs momentarily before eventually recovering automatically.

Conditions: This symptom occurs when a significant number of flows are simultaneously programmed and when debugs are turned on.

Workaround: Turn off the debugs or limit the number of debugs being turned on. Or wait until the flows are setup before running the show commands.

• CSCuj44931

Symptoms: The Mac Forwarding Table flows are all configured as static entries and all the flows have the same priority. Also, the MAC table supports the exact matching on the destination MAC address and the VLAN ID, and the only actions supported are drop and output to port.

However, the Openflow Agent will accept flow add/modify messages for the MAC flows with configurations for the flow priority and the idle/hard timeouts, and matching on other fields. These invalid matches/actions are ignored and the flow is still installed in the MAC table with only the correct supported attributes.

Conditions: This symptom occurs when the openflow switch is configured with pipeline 202 and flow add messages include unsupported matches and actions like setting the flow priority, setting the idle/hard timeouts, matching on IP src/dest address, TCP/UDP protocol, TOS, L4 src/dest ports etc.

Workaround: Install flows with only the supported matches and actions for the MAC Forwarding Table in Pipeline 202.

• CSCul67703

Symptoms: With pipeline 202, when the default-miss is configured to drop, two default flows are added, one each for the ACL and the MAC table. The ACL table installs a default rule of “permit” to allow packet matching in the MAC table. The MAC table installs a default rule of “drop” to drop all unmatched packets.

However, “show openflow switch 1 flows” displays both the rules to have the action “drop” instead of having the action “goto” or “normal” for the table 0.

Conditions: This symptom occurs when the switch is configured to use pipeline 202 and the default-miss is configured as “drop”.

Workaround: The show ip access-lists | beg onep command can be used to display the rule that is actually installed in the ACL table. The default rule will be similar to the following:

• CSCul70028

Symptoms: When the Openflow agent-installed default flow is modified by adding another default rule from the controller, the following issues are observed

1. The show openflow switch 1 flows controller command does not show this controller installed default flow

2. When the controller tries to fetch flow stats for this default flow, the Openflow agent does not provide the stats for this default flow.

Conditions: This symptom occurs when the Openflow agent-installed default flow is over-ridden by another default rule installed by the controller.

Workaround: The controller-installed default flow can be seen with the show openflow switch 1 flows default command. However, the stats for this default flow will not be sent to the controller.

• CSCul87549

Symptoms: The OpenFlow plugin incorrectly sends an OFPHFC_INCOMPATIBLE error in response to an OFPT_FLOW_MOD message.

Conditions: This symptom occurs when an attempt is made to program a flow using matches not supported by the configured pipeline.

Workaround: Ensure that the flows are programmed with matches/actions that are supported for the pipeline.

• CSCum08772

Symptoms: The Openflow agent gets killed due to lack of memory.

Conditions: This symptom occurs when there are flows installed that punt the packets to the controller. The packet buffer is not freed and gets leaked. This is seen with scale tests when packets get punted to the controller in large numbers at a very high rate.

Workaround: Do not add flows that punt the packets to the controller.

• CSCum22686

Symptoms: There is a mismatch between controller flows and the ACL entries.

Conditions: This symptom occurs while performing the open flow switch unconfiguration and configuration. Either copy/paste or copying to the running configuration may create the issue.

Workaround: Perform shutdown/no shutdown under the open flow switch configuration.

Open Caveats—Cisco Nexus 3000 Series Switches

NX-OS 6.0(2)U2(1)

This section describes possibly unexpected behavior in the underlying Cisco NX-OS system software which may affect the behavior of Cisco Plug-in for OpenFlow Agent 1.1.0. All the caveats listed in this section are open in Cisco NX-OS 6.0(2)U2(1). This section describes only severity 1, severity 2, and severity 3 caveats.

• CSCui25370

Symptom: CLI commands added by a container-based onePK application may not be removed when a container fails to install following a reboot.

Conditions: A container-based onePK application adds CLI commands to the router using the onePK CLI extensions feature. Upon reboot of the router the container fails to install properly. The CLI commands added prior to rebooting still remain even though the container is no longer installed.

Workaround: Install and uninstall the container for a second time to clean up the remaining CLI commands.

• CSCuj45245

Symptom: The following error message is seen:

Conditions: This symptom is an intermittent issue seen after some triggers, for example, clear controller command, switch unconf/conf, switch shut/noshut, cotroller unconf/conf etc.

Workaround: Virtual-service deactivate & reactivate fixes this issue.

• CSCuj70716

Symptom: The following system message seen on uninstalling ova. There is no functionality impact.

Conditions: The symptom is seen after uninstalling ova.

Workaround: No workaround is needed as there is no functionality impact.

• CSCul64410

Symptom: As per the Cisco Nexus 3000 design, the OpenFlow switch should allow a maximum of 16 output ports for the redirect action. However, the current release supports more than 17 redirect output ports.

Conditions: This symptom occurs when the OF controller is pushing down the flows with 17+ redirect output port action. The ACLMGR/AFM component allows to install those flows on the OF switch.

Workaround: Install flows with a maximum of 16 redirect output port actions.

• CSCul69881

Symptom: Flows are created for non-existing vlans.

Conditions: Install flows with non existing vlans on the agent via controller and the agent accepts the flows.

Correct Behaviour: Agent should reject the flow

Workaround: There is no workaround.

• CSCum06922

Symptom: When flow provisioned from the controller for non-ip ethertype with an output to port action, then the flow gets rejected.

Conditions: This symptom occurs only on flows provisioned via API(Openflow Agent).

Workaround: Modify the Openflow ACL via CLI and add the output to the port ACE manually.

• CSCum11307

Symptom: A core is observed while adding and deleting flows on Cisco Nexus 5000 series switches and Cisco Nexus 3000 series switches.

Conditions: The core that is observed seems to be an intermittent problem that does not occur or happen every time we add / delete 1500 flows. The element chunk memory that gets freed on xos_list_remove is not yet overwritten or used when the next call to xos_list_get_next() is made most of the times (xos is just freeing not setting the parameter to null).

Workaround: There is no workaround. This issue is not seen consistently.

• CSCum16186

Symptom: A deadlock in the Netstack or DPSS components blocks the openflow agent process until the process is killed by the watchdog timer.

Conditions: This symptom is seen when the openflow agent is repeatedly unconfigured, configured, shut, and no-shut in a continuous cycle. It usually takes about 15-20 cycles for the deadlock to occur and for the process to crash.

Workaround: Enter the switch unconfiguration or configuration command manually or slower with a few seconds between each command.

• CSCum23124

Symptom: Sometimes when openflow is enabled and unconfigured using the no openflow global configuration command, an error is seen when a proper cleanup of configuration is done. This issue has no functionality impact.

Conditions: This symptom is seen in the “no openflow” configuration.

Workaround: There is no workaround.

New Hardware Features in Cisco Plug-in for OpenFlow Agent 1.1.5.

There are no new hardware features in Cisco Plug-in for OpenFlow Agent 1.1.5.

New Software Features in Cisco Plug-in for OpenFlow Agent 1.1.5.

This section describes enhanced software features in Cisco Plug-in for OpenFlow Agent 1.1.5.

• OpenFlow Agent 1.1.5 includes support for the following command:

protocol-version version-info

This command configures the protocol version. The supported values for version-info are:

– 1.0—Configures device to connect to 1.0 controllers only

– 1.3—Configures device to connect to 1.3 controllers only

– negotiate—Negotiates the protocol version with the controller. The device uses 1.3 for negotiation.

The default value is negotiate.

• MAC source address and MAC destination address are match criteria for the Layer 3 ACL forwarding table.
• A new double-wide TCAM carving option called ifacl double-wide is added to support a 12-tuple match.
• Ethertype is now an optional field with additional match fields of source and destination MAC for Pipeline 201 and only source MAC for Pipeline 202. You can now use the Ethertype field as a wildcard match criteria when the size of the TCAM is configured for double wide interface ACLs.
• All unmatched packets are punted to the controller by default when TCAM carving is set to ifacl double-wide.
• Pipeline 203, which is supported only on the Nexus 3500 Series switches, supports an L3 ACL forwarding table.

New Hardware Features in Cisco Plug-in for OpenFlow Agent 1.1.4.

There are no new hardware features in Cisco Plug-in for OpenFlow Agent 1.1.4.

New Software Features in Cisco Plug-in for OpenFlow Agent 1.1.4.

This section describes enhanced software features in Cisco Plug-in for OpenFlow Agent 1.1.4.

• OpenFlow Agent 1.1.4 includes support for the following debug commands:

– debug openflow switch packet

This command displays the sequence of OpenFlow packets that are exchanged between the controller and the agent, and the type of packet exchanged with its header information and the OpenFlow error messages.

– debug openflow switch packet details

This command displays a hex dump of the OpenFlow packets that are exchanged between the controller and the agent.

• OpenFlow Agent 1.1.4 includes support for adding interface ranges of type of-port interface ethernet1/1-8 in the OpenFlow switch mode.

New Hardware Features in Cisco Plug-in for OpenFlow Agent 1.1.3.

There are no new hardware features in Cisco Plug-in for OpenFlow Agent 1.1.3.

New Software Features in Cisco Plug-in for OpenFlow Agent 1.1.3.

There are no new software features in Cisco Plug-in for OpenFlow Agent 1.1.3.

New Hardware Features in Cisco Plug-in for OpenFlow Agent 1.1.2.

There are no new hardware features in Cisco Plug-in for OpenFlow Agent 1.1.2.

New Software Features in Cisco Plug-in for OpenFlow Agent 1.1.2.

There are no new software features in Cisco Plug-in for OpenFlow Agent 1.1.2.

New Hardware Features in Cisco Plug-in for OpenFlow Agent 1.1.1.

There are no new hardware features in Cisco Plug-in for OpenFlow Agent 1.1.1.

New Software Features in Cisco Plug-in for OpenFlow Agent 1.1.1.

There are no new software features in Cisco Plug-in for OpenFlow Agent 1.1.1.

New Hardware Features in Cisco Plug-in for OpenFlow Agent 1.1.0.

There are no new hardware features in Cisco Plug-in for OpenFlow Agent 1.1.0.

New Software Features in Cisco Plug-in for OpenFlow Agent 1.1.0.

This section describes new and changed software features in Cisco Plug-in for OpenFlow Agent 1.1.0.

• OpenFlow-hybrid (Ships-in-night) model is supported.
• ACL and MAC Forwarding tables are supported and can be configured using pipelines.
• Transport Layer Security (TLS) is supported in Cisco Agent for OpenFlow and controller communications.
• VLAN priority has been introduced as a flow action.
• Configuration of default forwarding rule via openflow switch CLI.
