KVM Cable
The KVM cable (UCSX-C-DEBUGCBL) provides a connection into a Cisco UCS compute node, providing a DB-9 serial connector, a DB-15 connector, and a USB ports for a keyboard and mouse. With this cable you can create a direct connection to the operating system and the BIOS running on a compute node.
![](/c/dam/en/us/td/i/300001-400000/300001-310000/309001-310000/309412.jpg)
1 |
Oculink Connector to compute node |
2 |
DB-9 serial connector to host Console port |
3 |
USB connector to connect to single USB 3.0 port (keyboard or mouse) |
4 |
DB-15 connector to connect to a host VGA monitor |
