Cisco Secure Access Pre-Onboarding Checklist

Use this checklist to guide you through items needed before signing into Secure Access for the first time.

Application and team information

  • Identify at least 2 internal applications for testing the access controls. For each application, determine:
    • IP addresses/FQDNs
    • Ports/protocols
    • Decide if VPN, client-based Zero Trust Access or clientless ZTA
  • Decide which users and groups you want to include in testing.
  • Choose your SAML 2.0 compatible identity provider.
    • Out-of-the-box supported IdPs: AD FS, Microsoft Entra ID, Duo Security, Okta, OpenAM, and PingID
  • Request 2 SAML SSO applications in SAML IdP.
    • One SAML SSO application for client-based ZTA and clientless ZTA
    • One SAML SSO application for VPN

Network requirements

  • For private access
    • Select IP address ranges for VPN.
      • Each cloud data center to which users will connect must have one user and one management IP range Help.
    • If using IPsec tunnels for backhauling private access traffic (VPNaaS, ZTA):
      • For static routing: Route traffic to the Remote Access VPN pools and CGNAT pools (100.64.0.0/10)
      • For dynamic routing: Configure BGP peering with Secure Access platform
    • If using resource connectors:
      • Static or dynamic routing is only needed for VPNaaS Client IP pools
      • CGNAT is no longer needed or visible within customer networks
      • Internally submit a firewall request to allow access from the backhauling IPSec tunnel and/or resource connectors to internal DNS service and previously selected internal applications.
    • Optional: To facilitate IPSec site-to-site communication, open UDP ports 500 and 4500 Help.
  • For internet access
    • Reference the public IPs used for SSE functions Help: Secure Access Secure Web Gateway Services.
    • Select preferred integration method:
      • Branch to internet: Backhauling IPSec tunnels used for private access can also be used for internet access. Appropriate routes must be in place to steer the traffic.
      • Roaming user to internet: Remote access VPN can be used to route all traffic to internet, or roaming module can be used to route DNS and web traffic.
    • Highly recommend: Review your organization’s acceptable usage policy to understand which site categories should be blocked.

Computer requirements

  • Highly recommend: Use dedicated machine(s) for testing. Secure Access supports: PC, Mac, iOS Apple device and Samsung Android.
    • Ensure you have admin-level access to the machine(s).
    • To test client-based ZTA, the machine(s) must have Trusted Platform Module 2.0 (TPM) available.
    • Ensure that the Secure Client software has been downloaded and installed on the test machine(s).
